Operating Your Video Matrix Switcher
32
10.3 Toggling Between the AT ONCE and CONFIRM Modes
To toggle between the AT ONCE (default) mode and the CONFIRM mode,
press the TAKE button.
In CONFIRM mode: Actions require user confirmation and the TAKE LED
lights.
In AT ONCE mode: Actions do not require user confirmation and the
TAKE LED does not light.
When the TAKE LED flashes:
• You cannot toggle between the AT ONCE and CONFIRM modes
• You can execute the previous action, by pressing the TAKE
button
• You can cancel the previous action, by pressing a non-relevant
button (for example, the MENU button)
10.4 Switching
You can switch:
• One input to one output (see section
10.4.1 )
• Several inputs to several outputs (see section
10.4.2 )
• One input to all outputs (see section
10.4.3 )
10.4.1 Switching One Input to One Output
Pressing an OUT-IN combination when your VS-162V operates in the AT
ONCE mode implements the switch immediately.
To switch one input to one output (AT ONCE mode):
1. Press the appropriate OUT button.
The MATRIX display shows the two flashing digits, representing the
present input number connected to that specific output
1
out # x
. If the present
output is clear, the two flashing digits 00 appear in the MATRIX display.
The STATUS Display shows the message:
Where x is the output number
2. Press the appropriate IN button.
The output switches to the input and the MATRIX display shows the Input
# instead of the flashing digits.
The STATUS Display momentarily shows the message:
1 For example, pressing OUT button 9 shows the flashing digits 01 if input 1 was previously routed to OUT 9
