Operating Your Video Matrix Switcher
34
2. Press the appropriate IN button.
The MATRIX display shows the two flashing digits, representing the input
number and the TAKE LED flashes.
The STATUS Display shows
1
out # x
from in # y
the message:
Where x is the output number and y is the input number
3. Press the second appropriate OUT button, repeating step 1 above.
4. Press the appropriate
2
5. Continue with this OUT-IN button sequence, pressing the appropriate
OUT and IN buttons, as required. You can also combine an OUT-OFF
or OFF-OUT combination with this sequence.
IN button, repeating step 2 above.
6. After completing the sequence, press the TAKE button to confirm the
actions.
The inputs switch to the respective outputs, as the MATRIX display shows
(no digits flash) and the TAKE LED lights.
10.4.3 Switching One Input to All Outputs
To switch one input to all the outputs (in the AT ONCE mode):
1. Press the ALL button.
The MATRIX display shows all the sets of two flashing digits (each
representing the present input number for that respective output) flashing
simultaneously.
The STATUS Display shows the message:
all OUTs
2. Press the appropriate IN button.
This input switches to all the outputs and the MATRIX display shows the
identical non-flashing two digits (representing that input number).
To switch one input to all the outputs (in the CONFIRM mode, (the
TAKE LED is lit)):
1. Repeat steps 1 and 2 above.
The TAKE LED flashes.
2. Press the TAKE button to confirm the action.
The selected input switches to all the outputs and the TAKE LED lights.
The MATRIX display shows the identical two non-flashing digits
(representing that input number) for all outputs.
1 Continuously, within the limit of the timeout (approximately 30 seconds to one minute)
2 That corresponds with the second OUT button
