Configuring the VS-162V Video Matrix Switcher
13
13
7.2 Configuring 16x16 Multi-Channel Video Switchers
You can configure VS-162V units as a 16x16 multi-channel video switcher
for:
• s-Video (Y/C) (see section
7.2.1 )
• YUV (RGB) (see section
7.2.2 )
• RGBS (see section
7.2.3 )
You may need several VS-162V units to expand the system, as Table 4
defines. For example, for composite configuration, a single VS-162V unit
provides 16 inputs and 16 outputs. However, for s-Video (Y/C)
configuration you need two VS-162V units to provide 16 inputs and 16
outputs.
In a multi-channel video switcher configuration, one unit must be the master
(with DIP 6 OFF) while the other units are slaves (with DIP 6 ON).
The front panel of each slave unit is always locked and the MATRIX and
STATUS LCD displays do not illuminate. The slave units follow the master.
The master unit operates in the regular way
1
Note: To activate a multi-channel video switcher so that each unit is in the
same state from the outset, turn on the master unit power before turning on
the slave units.
, leading the slaves in the
background.
Table 4: 16x16 Multi-Channel Configurations
Configuration No. VS-162Vs Needed to
Make a 16x16 Switcher
Composite 1
s-Video (Y/C) 2
YUV / RGB 3
RGBS 4
7.2.1 Configuring a 2-Unit 16x16 Y/C Switcher
To configure a 16x16 s-Video (Y/C) video matrix switcher, combine two
VS-162V switchers. Connect as shown in Figure 7, substituting the C unit
for the U unit and ignoring the V unit. Set the DIP-switches as shown in
Figure 7 . Connect the communication line via the RS-232 or RS-485 control
interface as described in section 9.
1 The front panel is not locked and the MATRIX and STATUS LCD Displays illuminate
