AT-S106 Management Software Web Browser User’s Guide
215
Bridge/Spanning Tree/RSTP Basic Port
Port STP Status Enabled Enabled/Disabled
Port Priority 128 0-240, step:16
Port Path Cost 200,000 1-200,000,000
Bridge/Spanning Tree/RSTP Advanced Port
Port STP Status Enabled Enabled/Disabled
Port Edge Status FALSE TRUE/FALSE
Port PtoP Status AUTO AUTO/TRUE/FALSE
Bridge/Trunk Config/Trunking
Trunk Status Disabled Enabled/Disabled
Bridge/Trunk Config/LACP Group Status
LACP key none 1-10
MAX Number of ports in
a group 8 ports -
MAX number of groups
in a unit 10 groups -
Bridge/Trunk Config/Port Priority
Port Priority 1 0-255
Port mode of LACP
member port 1000Full-fixed -
Bridge/Mirroring
Mirroring Status Disabled Enabled/Disabled
Mirroring Port port 1 port 1-48
Ingress Mirrored Port 48 ports -
Egress Mirrored Port 48 ports -
Table 8. AT-S106 Management Software Default Settings (Continued)
Parameter
AT-GS950/48
Default Setting
Specifications
