Appendix A: AT-S106 Management Software Web Browser Default Parameters
214
System/Administration
Password Protection Enabled Enabled/Disabled
User name manager 1-12 characters (include 0-9 a-z A-Z ~!@#$%^&*()_+{}|:<>?-
=[]\;,./)
Manager Password friend 0-12 characters (include 0-9 a-z A-Z ~!@#$%^&*()_+{}|:<>?-
=[]\;,./)
Administrator Entry
Number 8 entries -
System/User Interface
SNMP Agent Enabled Enabled/Disabled
Physical Interface
Type port 1-48: 1000TX -
Admin Status Enabled Enabled/Disabled
Mode Auto port 1-44: Auto/10Half/10Full/100Half/100Full/1000Full
port 45-48 copper: Auto/10Half/10Full/100Half/100Full/1000Full
port 45-48 fiber: X
Jumbo Disabled Enabled/Disabled
Flow Control Disabled Enabled/Disabled
EAP Pass Disabled Enabled/Disabled
Bridge/Spanning Tree/RSTP
Global RSTP Status Disabled Enabled/Disabled
Bridge Protocol Version RSTP STP-Compatible/RSTP
Bridge Priority 0x8000 0x0000-0xF000, step:0x1000
Bridge Hello Time 2 seconds 1-9 seconds
Bridge Maximum Age 20 seconds 6-28 seconds
Bridge Forward Delay 15 seconds 11-30 seconds
Table 8. AT-S106 Management Software Default Settings (Continued)
Parameter
AT-GS950/48
Default Setting
Specifications
