Chapter 18: Management Software Updates
198
Downloading or Uploading a Configuration File via TFTP
This section describes how to download or upload a configuration file
using TFTP on an TFTP server. Before uploading or downloading a
configuration file onto the switch using TFTP, note the following:
ˆ Your network must have a TFTP server.
ˆ You must specify the path to the configuration file on the TFTP server.
ˆ Start the TFTP server software before you begin the download
procedure.
To download or upload an AT-S106 configuration file onto the switch using
a TFTP server, perform the following procedure:
1. From the menu on the left side of the home page, select the Tools
folder.
The Tools folder expands.
2. From the Tools folder, select the Config File Upload/Download
folder.
The Config File Upload/Download folder expands.
3. From the Config File Upload/Down folder, select via TFTP.
The Configuration Upload/Download via TFTP Page is displayed. See
Figure 65.
Figure 65. Configuration Upload/Download via TFTP Page
4. Enter the IP address of the TFTP server in the field next to the TFTP
Server IP parameter.
Configuration
File Upload
1. Select the Upload button to upload a configuration file from the switch
onto your PC.
2. The software immediately begins to upload the configuration file from
the switch to your PC.
