Allied Telesis AT-S106 User Manual
Page 160
Chapter 13: Spanning Tree and Rapid Spanning Tree Protocols
160
The RSTP Advanced Port Configuration Page is displayed. A partial
view is shown in Figure 50.
Figure 50. RSTP Advanced Port Configuration Page
This page displays the following information about the ports:
Port
Indicates ports 1 through 48 on the AT-GS950/48 switch. Use the All
row to apply the same settings to the STP Status, Priority, and Path
Cost fields to all the ports on your switch.
Trunk
Indicates the trunk assignment of a port.
Link
Indicates that the port’s link is active (Up) or inactive (Down).
