Chapter 10: Bandwidth Control
128
Setting Egress Rate Limiting
This procedure explains how to set Bandwidth levels and Status for
Egress Rate Limiting on each port of the AT-GS950/48 Gigabit Ethernet
Smart Switch.
To change the default settings, do the following procedure:
1. From the main menu on the left side of the page, select the Bridge
folder.
2. From the Bridge folder, select Bandwidth Control.
3. The Bandwidth Control folder expands.
4. From the Bandwidth Control folder, select Egress Rate Filtering.
The Egress Rate Limiting page is displayed. A partial view is shown in
Figure 40.
Figure 40. Egress Rate Limiting Page
5. To set the Bandwidth field, enter a number in the range of 1 to 15625.
You can use the option next to the ALL row to set all of the ports to the
same setting.
