CH. 13 MAN0924-01-EN
February 8, 2010 Page 78 of 124 # 1018
13.3
Establishing Communications
The preferred method of communicating between Cscape and a RX-371 is via USB port. The RX-371
OCS can communicate with Cscape using USB to USB, USB to serial adapters, serial port
communications via MJ1 Port, onboard Ethernet Port, CAN (CsCAN) or modems. For communications
other than USB or the MJ1 port please refer to the manual which ships with the communications adapter
hardware being used for programming.
13.3.1 To connect RX-371 with USB port: (Preferred method)
Connect a PC’s (Personal Computer running a Windows Microsoft operating system) USB port via USB
cable to the USB mini B port on the RX-371 OCS.
The PC will detect a new device has been plugged into the USB port.
Figure 13.1: Front Panel and USB Programming Connector
