MAN0924-01-EN CH. 16
February 8, 2010 Page 109 of 124 # 1018
When Add/Modify Message is clicked, the following screen appears.
Email Message Configuration
Trigger Variable
Settings An event is needed to trigger an Email communication from the controller to
the member(s) of a Group. Enter a bit reference in the Address field that
(when set to HIGH) causes the Email message associated with the trigger
to be sent to the specified Group member(s). An I/O name can be entered
or selected in the Name field.
On successful transmission of email, the trigger bit is made low by
firmware. In case of error in transmission, the status register is updated and
firmware keeps on trying to send email till trigger bit is made low by the
user.
Message/EMail
Attributes
Enter or select the group that the Email message is sent to.
