3.3. Mounting Orientation
3.3.1
RX-371 Mounting Clip
Figure 3.2: RX-371 Mounting Clips (4 clips)
3.3.2 RX-371 Mounting Orientation
NOTE:
There are NO orientation restrictions on the RX. However, the above orientation provides for optimum
readability of the screen and ease of use of the keypad.
Figure 3.3: RX-371 Mounting orientation
001OCS001
