Horner APG RX371 OCS HERX371C101 - Manual (Page 41)

MAN0924-01-EN CH.9
February 8, 2010 Page 41 of 124 # 1018
3. The following screen appears. In this configuration example, I/O modules are going to be
selected and configured for Base 2.
Figure 9.3: Main Base Screen appears with RX-371
Pressing the Auto Config Base button deletes any current settings from the configuration within Cscape,
and the I/O that is fitted to the target controller displayed. A Warning box appears and indicates that the
settings will be deleted from the configuration within Cscape. If OK, press Yes. Then press OK
.
Upon pressing the Base 2 tab, the following screen appears.
Any Base can be selected. It is not necessary to select bases in a specific order .
The Main base contains the slots directly located on the back of the RX-371.
