MAN0924-01-EN CH. 16
February 8, 2010 Page 105 of 124 # 1018
SMTP Server
SMTP Server IP:
The SMTP Server IP address of the email service provider
needs to be provided here. In case SMTP server IP needs
to be obtained from DNS server, select Obtain SMTP
Server IP Address from DNS Server checkbox. This will
enable DNS Server IP and SMTP Server Name edit-
boxes. Configure these with the information provided by
email service provider.
Port:
The default port for email configuration is set to 25 but can
be changed by user if required.
If ‘Get Settings from Register’ is checked:
DNS Server IP and SMTP Server IP needs to be provided
in 32-bit IP format in the defined register location.
Port number needs to be provided in 16-bit numeric format
at the defined register location.
SMTP Server Name (if required) needs to be provided at
the register mentioned followed by null termination or
space.
SMTP Authentication The firmware for E-Mail also supports Login type of SMTP
authentication. To use this feature, the Authentication
SMTP checkbox should be checked. The username and
password for authentication needs to be provided here.
If ‘Get Settings from Register’ is checked:
User Name and Password needs to be provided at the
register location mentioned followed by null termination or
space.
16.2.2 Email Target Directory Settings
Before creating Send Emails, a directory of email addresses needs to be created. Click on E-Mail
Directory button to configure email addresses.
Email address configuration is very similar to SMS Address configuration with email addresses replacing
phone numbers.
