MAN0924-01-EN CH.2
February 8, 2010 Page 15 of 124 # 1018
2.4 Product Specifications
Table 1 - RX371 Specifications
Display Type (LCD with
Backlight)
5.7” QVGA TFT
Display Size 5.7”
Display Screen Dimensions 320 x 240
Display Memory 2.75MB
Display Life Minimum 40000 hours (50% brightness, 25 deg C)
User Keys 5 user-defined Function keys and a System key
Screens supported 1023
Colors 32768
Primary power
10 – 30 VDC
Steady state current 0.8A @ 24 VDC, 2 A @ 10 VDC
Inrush current
30 A for 1 ms @ 24 VDC – DC Switched
2.5 A for 4 ms @ 24 VDC - AC Switched
Product Descriptions
Height 5.964” (151.49mm)
Width 7.682” (195.12mm)
Depth 3.223” (81.86mm)
Serial Ports RS232 & RS485. Software Selectable
Terminal Type Screw Type, 5mm removable
Weight 54 oz (1.53kg)
Portable Memory Micro SD card slot
Temperature & Humidity -30
°C to +60°C & 5 to 95% Non-condensing
Clock Accuracy
+/- 35 ppm maximum at 25
° C
(+/- 1.53 Minutes per Month)
Compliance USA:http://www.heapg.com/Pages/TechSupport/ProductCert.html
EUROPE: http://www.horner-pg.com/en/support/certification.aspx
2.5
Required and Suggested Accessories
The following table contains a list of required and suggested RX-371 accessories. Visit our website
(
http://www.heapg.com/ ) to view updates on new products and accessories.
Note: The RX-371 is not shipped with a programming cable in the box. To obtain a programming
cable, order HE500CBL300.
Table 2.1 – RX-371 Accessories
Part Number Description
HE500OSW232
Cscape Software Package. Includes Cscape CD, 9-pin OCS Programming Cable, RJ-45
Programming Cable, Documentation
HE500CBL300 OCS Programming Cable, 9-pin female (PC) to RJ-45 (OCS) - 6 feet.
HEUSB600
USB programming kit. Includes USB to RS-232 adapter, and 6-foot RS-232 cable with
D-sub connections. Requires HE500CBL300 to program the RX-371
Part Number Description
HE-MC1 Removable Media card - compatible with RX-371.
HE-MR1
Media Card Reader for HE-MC1. Portable device allows HE-MC1 to be plugged into the
USB port of personal computers as a portable hard drive
HE-X24-AS
Power supply 100-240VAC or 140-340VDC Switching supply that outputs 1.5 A / 3 A
(HE-X24-AS/AL) at 24 VDC. Mounts on Standard DIN rail.
HE-X24-AL
Power supply 100-240 VAC or 140-340 VDC Switching supply that outputs 1.5 A / 3 A
(HE-X24-AS/AL) at 24VDC. Mounts on Standard DIN rail.
