CH. 2 MAN0924-01-EN
February 8, 2010 Page 12 of 124 # 1018
Right Side
Bottom Side
Left Side
Figure 2.1: Visual Overview of RX-371
RX Model Network Screen Type Standard RX Features
RX-371 On-Board Ethernet
100BaseT
5.7"QVGA TFT
LCD with LED
backlight Micro SD
2 Serial Ports
Ethernet
USB A & USB B
Metal SmartStack Provide a wide variety of I/O options. Requires little space and are easy to install.
SmartStix Modules It is a family of remote I/O products.
Removable Media
USB B
Ethernet
USB A
MJ2
DIP Switches
MJ1 CAN Power
