-48-
APPENDIX “E” - GEMINI 5200 DUAL RATE W/ DISP C FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
55 TIMED OUTPUT 2 VALUE Range 0.01 to 599.99 sec.
61 DISPLAY C MULTIPLIER Not available in mode [41 3], Speed Difference
1 x1
2 x10
3 x100
4 x1000
5 x10000
62 RATE A CONVERSION FACTOR
1 Rate Per Second (x1)
2 Rate Per Minute (x60)
3 Rate Per Hour (x3600)
63 RATE MINIMUM UPDATE TIME
1 0.5 sec minimum/1 sec maximum
2 1 sec minimum/2 sec maximum
3 2 sec minimum/4 sec maximum
4 4 sec minimum/8 sec maximum
5 8 sec minimum/16 sec maximum Maximum rate = 7500 cps.
6 16 sec minimum/32 sec maximum Maximum rate = 3250 cps.
64 RATE A SCALE MULTIPLIER
1 x1000
2 x100
3 x10
4 x1
5 x0.1
6 x0.01
*Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
