-46-
APPENDIX “E” - GEMINI 5200 DUAL RATE W/ DISP C FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
41 UNIT PERSONALITY (-)Loads factory set code values*
+/-1 Dual Rate W/O Display C See Appendix "D" for function command code summary.
+/-2 Dual Rate W/ Ratio (A/B) Rate A & BÞDisplay value A & B,
Ratio (A/B)ÞDisplay Value C
+/-3 Dual Rate W/ Difference (A-B) Rate A & BÞDisplay value A & B,
Difference (A-B)ÞDisplay Value C
+/-4 Dual Rate W/ Draw [(A-B)/B] Rate A & BÞDisplay value A & B,
Draw [(A-B)/B]ÞDisplay Value C
42 RESET BUTTON & TERMINAL ACTUATION MODES
1 Reset Rate A Output(s) Reset only affects the output(s) and does not
2 Reset Rate B Output(s) change the rate display.
3 Reset Rate A & B Outputs
4 Reset Display C Output(s)
5 Reset Display C & Rate A Outputs
6 Reset Display C & Rate B Outputs
43 RATE B CONVERSION FACTOR
1 Rate Per Second (x1)
2 Rate Per Minute (x60)
3 Rate Per Hour (x3600)
45 RATE B SCALE MULTIPLIER
1 x1000
2 x100
3 x10
4 x1
5 x0.1
6 x0.01
46 DISPLAY C DECIMAL POINT & LEAD ZERO BLNKNG
(+) Leading Zero Blanking Enabled
(-) Leading Zero Blanking Disabled*
+/-1 No Decimal Point
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
