Red Lion G307K2 7" Operator Interface with TFT Display - Manual

1
GENERAL DESCRIPTION
The G307K2 is the perfect solution for applications that require the operator
to monitor and control more than just a single device. With three serial ports and
an Ethernet port, the 7" Kadet 2 can connect to multiple serial and Ethernet
devices simultaneously, including PLCs, motor drives, bar code scanners, etc.
The G307K2 performs the functions of a multiple protocol converter, using
three high-speed RS-232/422/485 communications ports and a 10 Base-T
Ethernet port. The Ethernet port supports up to four protocols simultaneously,
allowing dissimilar Ethernet based products to communicate with one another.
The SD card slot can be used to load the unit's configuration file, allowing
configuration changes to be made and saved to the card for later transfer.
The G3 Kadet 2 range of HMIs is programmed with Red Lion's free Crimson
3 software. Crimson offers easy to use drag and drop communications
configuration, while the embedded image library allows the programmer to
create intuitive screens and prompts for the operator.
SAFETY SUMMARY
All safety related regulations, local codes and instructions that appear in the
manual or on equipment must be observed to ensure personal safety and to
prevent damage to either the instrument or equipment connected to it. If
equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Do not use the controller to directly command motors, valves, or other
actuators not equipped with safeguards. To do so can be potentially harmful to
persons or equipment in the event of a fault to the unit.
CONTENTS OF PACKAGE
- G307K2 Operator Interface.
- Hardware packet for mounting unit into panel.
- Terminal block for connecting power.
- Spare fuse.
ORDERING INFORMATION
MODEL NO. DESCRIPTION PART NUMBER
G307K2 7" TFT Operator Interface G307K200
SD SD Card 1 SDxxxxxx
CBL Communications Cables and Adaptor 1 CBLxxxxx
G3FILM Protective Film G3FILM7K
1 Contact your Red Lion distributor or visit our website for selection of SD
cards, adapters and cables.
Note: If replacing Model G306K000, see Tech Note TNG3K6.
MODEL G307K2 - KADET 2 OPERATOR INTERFACE WITH 7" TFT DISPLAY
z CONFIGURED USING CRIMSON ® 3 SOFTWARE
z THREE SERIAL COMMUNICATIONS PORTS
(1 RS-232 AND 2 RS-232/422/485 PORTS)
z 10 BASE-T/100 BASE-TX ETHERNET PORT COMMUNICATES
WITH UP TO FOUR PROTOCOLS SIMULTANEOUSLY
z UNIT’S CONFIGURATION IS STORED IN NON-VOLATILE FLASH
MEMORY
z SD CARD SOCKET FOR LOADING DATABASE IN FIELD
z 7-INCH TFT LCD 32K COLOR 800 X 480 PIXEL DISPLAY
z NEMA 4/IP65 FRONT PANEL
z THREE FRONT PANEL LED INDICATORS
z POWER UNIT FROM 24 ±20% VDC
z RESISTIVE ANALOG TOUCHSCREEN
CAUTION: Risk Of Danger.
Read complete instructions prior to
installation and operation of the unit.
CAUTION: Risk of electric shock.
Bulletin No. G307K2-D
Drawing No. LP0889
Released 01/14
Tel +1 (717) 767-6511
Fax +1 (717) 764-0839
www.redlion.net
C US LISTED
UL
R
IND. CONT. EQ.
22SV
