-42-
APPENDIX “D” - GEMINI 5200 DUAL RATE W/O DISP C FUNCTION COMMAND CODE SUMMARY
CODE MODE DESCRIPTION COMMENTS
41 UNIT PERSONALITY (-)Loads factory set code values*
+/-1 Dual Rate W/O Display C Rate AÞDisplay A, Rate BÞDisplay B
+/-2 Dual Rate W/ Ratio (A/B) See Appendix “E” for a Function Command Code
+/-3 Dual Rate W/ Difference (A-B) Summary when in these modes
+/-4 Dual Rate W/ Draw [(A-B)/B]
42 RESET BUTTON & TERMINAL ACTUATION MODES
1 Reset Rate A Output(s) Reset only affects the output(s) and does not
2 Reset Rate B Output(s) change the rate display.
3 Reset Rate A & B Outputs
43 RATE B CONVERSION FACTOR
1 Rate Per Second (x1)
2 Rate Per Minute (x60)
3 Rate Per Hour (x3600)
44 RATE B MINIMUM UPDATE TIME
1 0.5 sec minimum/1 sec maximum
2 1 sec minimum/2 sec maximum
3 2 sec minimum/4 sec maximum
4 4 sec minimum/8 sec maximum
5 8 sec minimum/16 sec maximum Maximum rate = 7500 cps.
6 16 sec minimum/32 sec maximum Maximum rate = 3250 cps.
45 RATE B SCALE MULTIPLIER
1 x1000
2 x100
3 x10
4 x1
5 x0.1
6 x0.01
46 RATE B DECIMAL POINT & LEAD ZERO BLANKING
(+) Leading Zero Blanking Enabled
(-) Leading Zero Blanking Disabled*
* Polarity sign is displayed in front of the identifier, a (-) sign is displayed, a (+) sign is not.
