CODE 66 - “OPERATOR ACCESSIBLE FUNCTIONS” MODES (Cont’d)
[66 -1]
[66 -2] These Modes are the same as above with the
[66 -3] exception that manual reset is disabled.
[66 -4]
PRESET VALUES
Whenever the display value equals the Preset 1 or 2 Value, an output action
will occur. This action depends on the previously programmed modes. The
Preset Values may vary from -999,999 to 999,999. Refer to “Programming The
Presets, Scale Factors, And Timed Output Values” section for instructions on
entering the Preset Values.
“1” - PRESET 1 VALUE
“2” - PRESET 2 VALUE
SCALE FACTORS A & B
“3” SCALE FACTOR - The Scale Factor, for whichever Value (Rate A or B)
is currently being displayed, is accessed by pressing the “3” key. To access the
Scale Factor of the “other” rate display value, the “+/-” key would be pushed (to
change the display to the other value), then the “3” key would be pushed. The
actual rate (in pps) is multiplied by the Scale Factor, Scale Multiplier, and Rate
Conversion factor to obtain the desired display reading. The Scale Factor is used
primarily for conversion from existing pulses per unit of measure to the required
displayed units. This includes conversion from different units of measure (i.e feet
to meters, etc.). The Scale Factor Values may range from 0.0001 to 5.9999. Refer
to “Programming The Presets, Scale Factors, And Timed Output Values” section
for instructions on entering the Scale Factor Values.
-14-
