Selected Pool table
Use the Selected Pool table to view the list of pools that are selected.
Description
Item
The pool’s nickname and identifier.
Pool Name (ID)
Selected Pool Volumes table
Use the Selected Pool Volumes table to view the list of pool-VOLs that are selected.
Description
Item
The pool-VOL’s LDEV identifier.
LDEV ID
The pool-VOL’s LDEV name.
LDEV Name
The pool-VOLs's capacity.
Capacity
The pool-VOL’s parity group ID.
Parity Group ID
Does not apply to SS, whose RAID level is fixed.
RAID Level
The hard disk drive type and RPM.
Drive Type/RPM
(External LDEVs) External Storage and the value of the external LDEV tier rank
is shown.
The pool-VOL’s emulation type.
Emulation Type
The total number of pool-VOLs.
Total
Edit Pools wizard
The Edit Pools wizard consists of the Edit Pools window and the Confirm window.
