Setting items

In the following table, items that are marked with an asterisk (*) require configuration.

Description

Item

The pool’s type.

Pool Type*

Value: Snapshot

The system type.

System Type

Value: Open

You can only select Open if the pool type is Snapshot.

THP/Smart only.

Smart Pool

The pool-VOL’s hard disk drive type and RPM.

Drive Type/RPM*

Values:

Mixable: This value is shown if the volume is a Smart volume.

External Storage: This value is shown if the volume is an external volume.

The pool-VOL’s RAID level.

RAID Level*

Values:

Hyphen (-): If you select External Storage as the Drive Type/RPM, a hyphen
(-) is shown.

Mixable: This value is shown if the volume is a THP/Smart volume.

80

Snapshot GUI reference
