Description
Item
•
CCC: LU number
•
XX:YY:ZZ: LDKC number:CU number: LDEV number
Only one path is listed, which is the path connected to the first port in the tree view.
A device ID ending in # (e.g., 00:00:3C #), indicates that the LDEV is an external volume. For
more information about external volume, see the HP XP P9000 External Storage for Open and
Mainframe Systems User Guide.
A device ID ending in X (e.g., 00:00:3C X) indicates that the LDEV is a THP V-VOL. For more
information about V-VOL, see the HP XP P9000 Provisioning for Open Systems User Guide.
The pair’s consistency group number. When the consistency group is not specified, three hyphens
(---) are shown.
CTG
Shows the status of the S-VOL. When data is not written in the S-VOL, three hyphens (---) are
shown. When the data is written in the S-VOL, W is shown.
SvolMode
Not for SS, three hyphens (---) are shown.
Copy Pace
Indicates the percentage of pair synchronization, and changes based on the pair status.
Sync.
Values:
•
For volumes or pairs in “SMPL” or “SMPL (PD)” status, dashes (---) are shown.
•
The percentage (%) of data in the S-VOL and P-VOL for volumes in “COPY”, “PAIR”,
“COPY(RS)/COPY”, “COPY(RS-R)/RCPY”, “PSUS”, or “PSUE” status.
Emulation type of the volume.
Emulation
Volume storage capacity in megabytes.
Capacity (MB)
P-VOL cache logical partition.
CLPR (P)
S-VOL cache logical partition.
CLPR (S)
Commands you can perform. If you select and right click the SS pair volumes in the volume list,
the menus in the following table are shown. For more information about the command
descriptions, see the following table.
Right-click command
menu
If the total number of the volumes in the storage system has exceeded the maximum number of
volumes, multiple pages exist. Click to open the previous page in the list.
Previous
Note: If only one page exists, this button is unavailable.
For more information about the maximum number of pool-VOLs allowed in a data pool, see
“Consistency group system requirements” (page 11)
.
If the total number of the volumes in the storage system has exceeded the maximum number of
volumes, multiple pages exist. Click to open the next page of the volume list.
Next
Note: If only one page exists, this button is unavailable.
For more information about the maximum number of pool-VOLs allowed in a data pool, see
“Consistency group system requirements” (page 11)
.
If a volume or pair does not exist, Message is shown. If Message is shown in the Volume list,
click a different icon in the tree in the left area of the Pair Operation window.
Message
Preview list
The Preview list shows the operations and changes you have made from the Pair Operation window.
You can review your changes, modify the operation or your changes, and apply them to the storage
system:
•
To modify an operation, right-click the row and select Delete or Modify.
•
To display error messages, click Error.
