Description

Item

Values:

Total: The pool’s total capacity

Unit of capacity: Click Option to select the unit of capacity.

One block equals 512 bytes and one page equals 256 kilobytes in SS pool
capacity.

Used: The amount of pool capacity that is used.

Used (%): The percentage of pool capacity that is used.

If you clicked Option to change the unit of capacity to Cylinder, a hyphen (-)
is shown.

Information about the pool threshold.

User-Defined Threshold(%)

Values:

Warning: Warning threshold is shown.

Depletion: Depletion threshold is shown.

For SS, a hyphen (-) is shown.

Caution: You must define both user-defined thresholds. Defining only one of the
user-defined pool thresholds enables the system threshold (fixed at 80%). If the
pool’s used capacity exceeds the user-defined threshold, SIM code 620XXX is
reported. You cannot set the system threshold.

Shows the following information about the pool’s subscription:

Subscription (%)

Current: Current subscription.

For SS, a hyphen (-) is shown.

Limit: Subscription limit.

For SS, a hyphen (-) is shown.

Shows the type of pool.

Pool Type

Value: Snapshot

The pool’s hard disk drive type and RPM.

Drive Type/RPM

If multiple drive types or RPMs exist in a pool, Mixed is shown.

(External LDEVs) External Storage and the value of the external LDEV tier rank
is shown.

Shows whether Smart is enabled or disabled.

Tier Management

For SS, a hyphen (-) is shown.

The CLPR (cache logical partition) set for the pool-VOL.

CLPR

For pools other than for SS, a hyphen (-) is shown.

Shows whether you can delete the pool-VOL.

Shrinkable

For SS, a hyphen (-) is shown because its pool is not shrinkable.

The monitoring mode set for the pool, Continuous Mode or Period Mode.

Monitoring Mode

The status of pool monitoring.

Monitoring Status

Conditions:

In Progress: Monitoring is being performed.

During Computation: Calculating is being processed.

If a condition is not present, a hyphen (-) is shown.

The latest monitoring data.

Recent Monitor Data

Pools window

71
