COMMAND DETAILS

99

Parameter/
Return Parameter

EXITs

Sets the NoGo condition to when the
input signal exceeds the limit boundary.

ENTers

Sets the NoGo condition to when the
input signal stays within the limit
boundary.

Example

:GONogo:NGDefine EXITs
Sets the Go/NoGo condition to EXITs.

:GONogo:SOURce

Set

Query

Description

Sets the source for the Go/NoGo signal.

Syntax

:GONogo:SOURce {CH1|CH2|CH3|CH4|?}

Parameter/
Return Parameter

CH1~CH4

Example

:GONogo:SOURce CH1
Sets the source to CH1.

:GONogo:VIOLation

Set

Query

Description

Sets or returns actions for the Go/NoGo violations.

Syntax

:GONogo:VIOLation
{STOP|STOP_Beep|CONTinue|CONTINUE_Beep|?}

Parameter/
Return Parameter

STOP

The waveform will be frozen.

STOP_Beep

The waveform will be frozen and
a beep will be output.

CONTinue

Ignore the violation.

CONTINUE_Beep

Output a beep, but continue to
monitor the signal.

Example

:GONogo:VIOLation STOP
Sets violation action to STOP.
