GDS-3000 Programming Manual
74
:REF:OFFSet
Set
Query
Description Sets or returns the selected reference waveform
vertical position (offset).
Syntax :REF:OFFSet { | ?}
Parameter Reference
waveform
1,2,3,4 REF1~REF4 Vertical offset
Return parameter Returns the reference waveform vertical position
as .
Example :REF1:OFFSet -5.000E-2
Selects reference 1, and then sets the vertical
position to -50mV/mA.
:REF:SCALe
Set
Query
Description Sets or returns the selected reference waveform
vertical scale.
Syntax :REF:SCALe { | ?}
Parameter Reference
waveform
1,2,3,4 REF1~REF4 Vertical scale
Return parameter Returns the reference waveform vertical scale as
.
Example :REF1:SCALe 5.000E-2
Selects reference 1, and then sets the vertical scale
to 50mV|mA/div.
