GDS-3000 Programming Manual

54

Return parameter Returns the ratio delta as V/A| V/V|A/A

Example

:CURSor:XY:RATio:DELta?
5.39E+1
Returns the ratio delta as 53.9.

Display Commands

:DISPlay:INTensity:WAVEform .................................... 54

:DISPlay:INTensity:GRATicule .................................... 54

:DISPlay:PERSistence .................................................. 55

:DISPlay:GRATicule ..................................................... 55

:DISPlay:WAVEform .................................................... 56

:DISPlay:INTensity:WAVEform

Set

Query

Description

Sets or queries the waveform intensity level.

Syntax

:DISPlay:INTensity:WAVEform { | ?}

Parameter

Range

0.0E+0~1.0E+2

0~100%

Return parameter Returns the intensity as

Example

:DISPlay:INTensity:WAVEform 5.0E+1
Sets the waveform intensity to 50%.

:DISPlay:INTensity:GRATicule

Set

Query

Description

Sets or queries the graticule intensity level.

Syntax

:DISPlay:INTensity:GRATicule { | ?}

Parameter

Range

1.0E+0~1.0E+2

10~100%

Return parameter Returns the intensity as
