COMMAND DETAILS

43

Parameter

Source number: 1/2/3/4

CH1~4

Channel 1 to 4

REF1~4

Reference waveforms 1 to 4

Return parameter Returns the source for the source 1 or 2.

Example

:MATH:DUAL:SOURce1 CH1
Sets source1 as channel 1.

:MATH:DUAL:OPERator

Set

Query

Description

Sets the math operator for dual sourced math
operations.

Syntax

:MATH:DUAL:OPERator {PLUS | MINUS | MUL|
DIV|?}

Parameter

PLUS

+ operator

MINUS

- operator

MUL

operator

DIV

÷ operator

Return parameter Returns operator type.

Example

:MATH:DUAL:OPERator PLUS
Sets the math operator as plus (+).

:MATH:DUAL:POSition

Set

Query

Description

Sets the vertical position of the displayed math
result expressed by division.

Syntax

:MATH:DUAL:POSition

Parameter

Vertical position

Depends on the vertical scale (Unit/Div)

Return parameter Returns the position as .
