|Address | | |Address Port|Thr|Boundary | |
Prio | Interval
---------+---------------+----+---+-----------------------+---+---------+-------
+------+---------+
e1/1/7 30.0.0.1 SM Ena Itself 1 None default
1 3000ms
Total Number of Interfaces : 1
Syntax: show ip pim [vrf vrf-name ] interface [ethernet port-number | loopback num | ve num |
tunnel num ]
The vrf keyword allows you to display multicast boundary information for the VRF instance identified by
the vrf-name variable.
The ethernet parameter specifies the physical port.
The loopback parameter specifies the loopback port.
The veparameter specifies a virtual interface.
The tunnel parameter specifies a GRE tunnel interface that is being configured. The GRE tunnel
interface is enabled under the device PIM configuration.
The following table describes the output from the show ip pim interface ethernet command.
Field Description
Interface Name of the interface.
Local Address IP address of the interface.
Mode PIM mode, dense or sparse..
St PIM status for this interface, enabled or disabled.
Designated Router Address, Port Address, port number of the designated router.
TTL Thr Time to live threshold. Multicast packets with TTL less than this threshold value
are not be forwarded on this interface.
Multicast Boundary Multicast boundary ACL, if one exists.
VRF Name of the VRF.
DR Prio Designated router priority assigned to this inerface.
Override Interval Effective override interval in milliseconds.
PIM Dense
NOTE
This section describes the "dense" mode of PIM, described in RFC 3973. Refer to
PIM Sparse on page
95 for information about PIM Sparse.
