Output from the show ipv6 mld vrf cs static command TABLE 44
Field Description
Group Address The address of the multicast group.
Interface Port List The physical ports on which the multicast groups are received.
Displaying MLD traffic
To display information on MLD traffic, enter a command such as the following.
device# show ipv6 mld traffic
Recv QryV1 QryV2 G-Qry GSQry MbrV1 MbrV2 Leave IS_IN IS_EX ToIN ToEX ALLO BLK
e3/1 0 0 0 0 0 0 0 0 0 0 0 0 0
e3/2 0 0 0 0 0 0 0 0 0 0 0 0 0
e6/18 0 0 0 0 0 176 0 110 0 0 0 66 0
e6/19 0 0 0 0 0 176 0 110 0 0 0 66 0
e6/20 0 0 0 0 0 176 0 110 0 0 0 66 0
e6/25 0 0 0 0 0 176 0 110 0 0 0 66 0
l1 0 0 0 0 0 0 0 0 0 0 0 0 0
Send QryV1 QryV2 G-Qry GSQry
e3/1 0 0 0 0
e3/2 0 0 0 0
e6/18 0 10 10 0
e6/19 0 10 10 0
e6/20 0 10 10 0
e6/25 0 10 10 0
l1 0 0 0 0
R2#
The report has a Receive and a Send section.
Syntax: show ipv6 mld [ vrf vrf-name ] traffic
The vrf parameter specifies that you want to display information on MLD traffic for the VRF specified by
the vrf-name variable.
The following table displays the output from the show ipv6 mld traffic command.
Output from the show ipv6 mld traffic command TABLE 45
Field Description
QryV1 Number of general MLDv1 queries received or sent by the virtual routing interface.
QryV2 Number of general MLDv2 queries received or sent by the virtual routing interface.
G-Qry Number of group-specific queries received or sent by the virtual routing interface.
GSQry Number of source specific queries received or sent by the virtual routing interface.
MbrV1 Number of MLDv1 membership reports received.
MbrV2 Number of MLDv2 membership reports received.
Leave Number of MLDv1 "leave" messages on the interface. (See 2_Ex for MLDv2.)
Is_IN Number of source addresses that were included in the traffic.
Displaying MLD traffic
