show command output differences between 07.4.00 and 08.0.xx

show ip

pim mcache

1.2.3.4

Brocade#show ip pim mc 90.1.1.32 226.0.0.201

IP Multicast Mcache Table

Entry Flags : SM - Sparse Mode, SSM - Source Specific Multicast, DM -

Dense Mode

RPT - RPT Bit, SPT - SPT Bit, LSRC - Local Source,

LRCV - Local Receiver

HW - HW Forwarding Enabled, FAST - Resource Allocated,

TAG - Need For Replication Entry

REGPROB - Register In Progress, REGSUPP - Register

Suppression Timer

MSDPADV - Advertise MSDP, NEEDRTE - Route Required for

Src/RP, PRUN - DM Prune Upstream

Interface Flags: IM - Immediate, IH - Inherited, WA - Won Assert

MJ - Membership Join, MI - Membership Include, ME -

Membership Exclude

BR - Blocked RPT, BA - Blocked Assert, BF - Blocked

Filter, BI - Blocked IIF

1 (90.1.1.32, 226.0.0.201) in v90 (tag e1/3/2), Uptime 02:09:34,

Rate 0 (SM)

Source is directly connected. RP 25.0.0.25

Flags (0x2042cce1) SM SPT L2REG LSRC HW FAST TAG MSDPADV

fast ports: ethe 1/1/13

AgeSltMsk: 1, FID: NotReq, DIT: 2 , RegPkt: 0, AvgRate: 0,

profile: none

Forwarding_oif: 1, Immediate_oif: 1, Blocked_oif: 0

L3 (HW) 1:

TR(e1/1/13,e1/1/13)(VL110), 01:28:23/174, Flags: IM IH

L2 FID: 105c Src-Vlan: 90

REP_IDX 2: L:VL110 FID: 1073 FSID: 2a680a00

More detailed
explanation
provided for the
acronyms in the
output.

show ip

pim sparse

Brocade#show ip pim sparse

Global PIM Sparse Mode Settings

Maximum Mcache : 4096 Current Count : 605

Hello interval : 30 Neighbor timeout : 105

Join/Prune interval : 60 Inactivity interval : 180

Hardware Drop Enabled : Yes Prune Wait Interval : 3

Bootstrap Msg interval : 60 Candidate-RP Msg interval : 60

SSM Enabled : No SPT Threshold : 1

Route Precedence : mc-non-default mc-default uc-non-default uc-

default

More fields added
for detailed PIM
parameters.

show ip

pim mcache

Brocade#show ip pim mc

A.B.C.D Multicast cache IP source or group address

counts Display only the count of entries

dense Display only the Dense entries

dit-idx Display on the entries using this resource

fid Display on the entries using this resource

g_entries Display only the (*, G) entries

receiver Display the IGMP/PIM Receiver

sg_entries Display only the (S, G) entries

sparse Display only the Sparse entries

ssm Display only the SSM entries

| Output modifiers

More options such
as "counts",
"dense", etc. have
been added.
