<6. PARAMETERS>
6-13
IM 01F06A00-01EN
(3) Item C : BASIC SETUP
These items are for the basic parameters with
setting before shipment.
The parameters which are set in B are not
necessary to set in C.
A value in “( )” is the data corresponding to
indicator.
The parameters, C20 to C50, are not
indicated when option code “/MV” is
selected and parameter item is selected in
F10 except “Monitor only” or “Not Use”.
[C10: TAG NO] Tag. No
Set Tag. No. (16 characters)
Available characters are as follows.
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a
b c d e f g h i j k l m n o p q r s t u v w x y z 0 1 2 3 4 5 6 7
8 9 . SPACE / - , +
* ) ( ’ & % $ # “ !
F0603.ai
[C20:FLUID] Flowrate unit
Set the fl owrate unit below.
Item Description
LIQUID : Volume (0) Volumetric fl ow of Iiquid measuring
GAS/STEAM : Volume (1) Volumetric fl ow of gas or steam
measuring
LIQUID : Mass (2) Mass fl ow of liquid measuring
GAS/STEAM : Mass (3) Mass fl ow of gas or steam
measuring
GAS : STD/Normal (4) Volumetric fl ow at Standard
condition
The following items should be done in case
of which “C20” is “LIQUID : Volume” or
“GAS/STEAM : Volume”.
[C22:VOLUME UNIT] Volumetric unit
Select the unit of volumetric fl ow from m 3 (0),
k m 3 (1), l(2), cf(3), m cf(4), k cf(5), USgal(6),
k USgal(7), UKgal(8), k UKgal(9), bbl(10),
m bbl(11), k bbl(12).
The following items should be done in case
of which “C20” is “LIQUID: Mass” or “GAS/
STEAM : Mass”
[C25:DENSITY UNIT] Density Unit of Flow
measurement
Select the unit of density from kg/m 3 (0), lb(1), lb/
USgal(2), lb/UKgal(3).
[C26:DENSITY f] Density at normal
operation conditions
Set the density value of the fl uid at operating
condition for mass fl ow unit.
[C27:MASS UNIT] Mass fl owrate unit
Select the mass fl owrate unit from kg(0), t(1), lb(2),
k lb(3).
The following item should be done in case
of which “C20” is “GAS/STEAM : Volume”.
[C30:TEMP UNIT] Fluid temperature unit at
operating conditions
Select temperature unit at operating condition from
“degC (0), degF (1)”.
[C31:TEMP f] Fluid temperature at
operating conditions
Set fl uid temperature at operating condition.
The following items should be done in case
of which “C20” is “GAS/STD : Normal”.
[C32:TEMP b] Fluid temperature at
standard/normal conditions
Set the values of Fluid temperature at standard
condition.
[C33:PRESS UNIT] Pressure unit
Select the unit of pressure.
BRAIN HART
MPa abs (0) MPa abs (0)
kPa abs (1) kPa abs (1)
bar abs (2) kg/cm 2 a (2)
kg/cm 2 a (3) bar abs (3)
psia (4) psia (4)
[C34:PRESS f] Absolute pressure at
operating conditions
Set the absolute pressure at operating condition.
[C35:PRESS b] Absolute pressure at
standard/normal condition
Set the absolute pressure at normal condition.
[C36:DEVIATION] Deviation factor
Set deviation factor.
[C37:STD/NOR UNIT] Volumetric unit at
normal conditions
Select volumetric unit at normal condition from
Nm
3 (0), k Nm 3 (1), M Nm 3 (2), Nl(3), Sm 3 (4),
k Sm 3 (5), M Sm 3 (6), Sl(7), scf(8), k scf(9), M scf(10).
N: Normal
S: Standard
