<13. GENERAL SPECIFICATIONS>
13-34
IM 01F06A00-01EN
 Stainless Steel Housing: DY015/E1 to DY100/E1
 Wafer Type
ELECTRICAL CONNECTION
Only for the following
explosion protected type
Flameproof (ATEX, IECEx)
Locking Screw
EARTH TERMINAL
L
B
ø
D
H
20 (0.78)
5
(0.19)
32.5
(1.28)
2 - øG
шC
14.5 (0.57)
58 (2.28)
ш
78 (3.07)
91 (3.58)
H1
75.5 (2.97)
F
E
JIS G1/2 Female
ANSI 1/2 NPT Female
ISO M20×1.5 Female
TYPE REMOTE
MODEL CODE DY015/E1 DY025/E1 DY040/E1
PROCESS
CONNECTION
AJ1 AJ2 AJ4 AA1 AA2 AA4
AD1
to
AD4 AJ1 AJ2 AJ4 AA1 AA2 AA4
AD1
to
AD4 AJ1 AJ2 AJ4 AA1 AA2 AA4
AD1
to
AD4
L 70 (2.76) 70 (2.76) 70 (2.76)
B 35 (1.38) 35 (1.38) 35 (1.38)
C 14.6 (0.57) 25.7(1.01) 39.7 (1.56)
D 35.1 (1.38) 50.8 (2.00) 73 (2.87)
H 235.5 (9.27) 245.4 (9.66) 263.5 (10.37)
H1 127 (5.00) 129 (5.08) 136 (5.35)
E
49.5
(1.95)
49.5
(1.95)
56.6
(2.23)
42.7
(1.68)
47.1
(1.85)
47.1
(1.85)
46
(1.81)
63.6
(2.50)
63.6
(2.50)
67.2
(2.65)
56
(2.20)
62.9
(2.48)
62.9
(2.48)
60.1
(2.37)
74.2
(2.92)
74.2
(2.92)
84.9
(3.34)
69.7
(2.74)
80.8
(3.18)
80.8
(3.18)
77.8
(3.06)
F
24.7
(0.97)
24.7
(0.97)
28.3
(1.11)
21.4
(0.84)
23.5
(0.93)
23.5
(0.93)
23
(0.91)
31.8
(1.25)
31.8
(1.25)
33.6
(1.32)
28
(1.10)
31.4
(1.24)
31.4
(1.24)
30.1
(1.19)
37.1
(1.46)
37.1
(1.46)
42.4
(1.67)
34.8
(1.37)
40.4
(1.59)
40.4
(1.59)
38.9
(1.53)
G
13
(0.51)
13
(0.51)
17
(0.67)
14
(0.55)
14
(0.55)
14
(0.55)
13
(0.51)
17
(0.67)
17
(0.67)
17
(0.67)
14
(0.55)
17
(0.67)
17
(0.67)
13
(0.51)
17
(0.67)
17
(0.67)
21
(0.83)
14
(0.55)
20
(0.79)
20
(0.79)
17
(0.67)
WEIGHT kg (lb) 2.9 (6.4) 3.8 (8.4) 4.4 (9.7)
TYPE REMOTE
MODEL CODE DY050/E1 DY080/E1 DY100/E1
PROCESS
CONNECTION
AJ1 AJ2 AJ4 AA1 AA2 AA4
AD1
to
AD4 AJ1 AJ2 AJ4 AA1 AA2 AA4
AD1
AD2
AD3
AD4 AJ1 AJ2 AJ4 AA1 AA2 AA4
AD1
AD2
AD3
AD4
L 75 (2.95) 100 (3.94) 120 (4.72)
B 37.5 (1.48) 40 (1.57) 50 (1.97)
C 51.1 (2.01) 71 (2.80) 93.8 (3.69)
D 92 (3.62) 127 (5.00) 157.2 (6.19)
H 295 (11.61) 329.5 (12.97) 359.6 (14.16)
H1 158 (6.22) 175 (6.89) 190 (7.48)
E
45.9
(1.81)
49.8
(1.96)
48.6
(1.91)
48.6
(1.91)
57.4
(2.26)
61.2
(2.41)
65.1
(2.56)
64.4
(2.54)
64.4
(2.54)
61.2
(2.41)
61.2
(2.41)
67
(2.64)
70.8
(2.79)
78.5
(3.09)
72.9
(2.87)
76.6
(3.02)
82.6
(3.25)
68.9
(2.71)
72.7
(2.86)
F
55.4
(2.18)
60.1
(2.37)
58.7
(2.31)
58.7
(2.31)
69.3
(2.73)
73.9
(2.91)
78.5
(3.09)
77.7
(3.06)
77.7
(3.06)
73.9
(2.91)
73.9
(2.91)
80.8
(3.18)
85.5
(3.37)
94.7
(3.73)
88
(3.46)
92.5
(3.64)
99.7
(3.93)
83.1
(3.27)
87.8
(3.46)
G
17
(0.67)
17
(0.67)
17
(0.67)
17
(0.67)
17
(0.67)
21
(0.83)
21
(0.83)
20
(0.79)
20
(0.79)
17
(0.67)
17
(0.67)
17
(0.67)
21
(0.83)
23
(0.91)
17
(0.67)
20
(0.79)
23
(0.91)
17
(0.67)
21
(0.83)
WEIGHT kg (lb) 6.1 (13.4) 9.5 (20.9) 12.9 (28.4)
(Note 1) The holes are not provided.
(Note 2) The fl ow direction is opposite (right to left when facing onto indicator) in case of code/CRC.
Unit : mm
(approx. inch)
