<6. PARAMETERS>
6-8
IM 01F06A00-01EN
Item Name R / W Data Range Unit
Decimal
Point
Remark
Initial
Value
Disp. U / D (*1)
F29 TEMP b W -999.9 to 999.9 F28 1 Temperature of standard condition 15.0 D L
F30 1st coef W -32000 to 32000 1/F28 0 to 5 1st temperature coeffi cient 1.0 D L
F31 2nd coef W -32000 to 32000 1/F28 2 0 to 5 2nd temperature coeffi cient 1.0 D L
F32 MASS UNIT W kg (0)
t (1)
Ib (2)
k Ib
(3)
Selection of mass fl ow rate unit (0) D L
F35 TIME UNIT W /s (0)
/m (1)
/h (2)
/d (3)
Selection of time unit 1 D L
F40 FLOW SPAN W 0.00001 to 32000 FU+35 0 to 5 Flow span 0.5 D L
F45 DAMPING W 0 to 99 sec 0 Damping 4 D L
F50 TEMP DAMPING W 0 to 99 sec 0 Damping for temperture output 4 D L
F52 CABLE LENGTH W 0 to 30 m 0 Cable length for signal cable (0m in
case of integral version) 0 D L
F55 A/OUT SELECT W FLOW (0)
TEMP (1)
Selection of analog output (0) D L
(Indicate and Set only for F55: TEMP)
F56 TEMP 0% W -999.9 to 999.9 D20 1 Temperture value at 0% -40 D L
F57 TEMP 100% W -999.9 to 999.9 D20 1 Temperture value at 100% 250 (*2) D L
F58 TEMP ERR OUT W 0% (0)
OUT LIMIT(H) (1)
TEMP f (2)
Selection of themometer error output
when “F55: TEMP” is selected (A
value of OUT LIMIT(H) depend on
D30) 1 D L
F60 SELF CHECK R GOOD
ERROR Self-diagnostic message
(*1) : Available for 3.10 or greater version that can be checked in K50.
(*2) : If 7.00 or less version that can be checked in K50, Initial Value is 260.
