<13. GENERAL SPECIFICATIONS>
13-41
IM 01F06A00-01EN
 Flameproof Packing Adapter (/G11, /G12)
T1
T2
L
18
(0.71)
G
F
D
C
16.5
(0.65)
*Packing
(Choose from the table below
depend on cable outside diameter)
Adapter body (M. Screw)
Packing case
Hexagon socket set screw
O-Ring
Packing *
O-Ring
O-Ring
Washer
Union nut
Packing gland
Clamp ring
Clamp nut
O-Ring
Hexagon socket set screw
B.coupling
Cable (user’s scope)
Size
Cable outer diameter
Packing dimensions
Identifi cation
mark
Weight
kg (lb)
T1 T2 C D L F G
G 1/2 G 1/2
35
(1.38)
39
(1.54)
94.5
(3.72)
ø8.0 to ш10.0
(ш0.31 to ш0.39)
ш10.0
(ш0.39)
ш20.0
(ш0.79)
16 8-10
0.26
(0.57)
ш10.0 to ш12.0
(ш0.39 to ш0.47)
ш12.0
(ш0.47)
16 10-12
Unit : mm
(approx. inch)
