<13. GENERAL SPECIFICATIONS>
13-9
IM 01F06A00-01EN
(Note 5) Refer to Subsection 13.3.1 “Option Multi-Variable (Built-In Temperature Sensor) Type (/MV)”
In case of Remote type detector (DY***-N), select “/MV” both DY and DYA.
(Note 6) /NM can not combine with Remote type (DY***-N).
(Note 7) ATEX Flameproof Approval /KF2 and IECEx Flameproof Approval /SF2 are not Available.
(Note 8) • Cryogenic version /LT is not available.
• High process temperature version /HT and Multi-variable type /MV for DY025/R1 and DY040/R2 is not available.
• Explosion protected types, SAA /SS1 are not available.
•
Flange type only and available process connections are JIS10k, 20k (BJ1, BJ2) and ANSI class 150, 300
(BA1,BA2,BS1,BS2).
• Model Code (A) means “DY***-” nominal size.
(Note 9) • Applicable for Option code /FF1, /KF2, /KS1, /FS1 and /SF2.
• Not applicable for Option code /P1, /P2, /P7, /X1, /X2, /HT, /LT, /SB /JF3, /FS1, /CF1, /CS1, /CF11, /CS11 and /SS1.
•
The materials of exterior parts, name plate, screw, bolts on the stainless steel housing and bracket, u-bolt, nuts for DYA/
E1 and tag plate for /E1/SCT are JIS SUS316 or SUS316L.
(Note 10) The wetted parts materials conform to NACE material recommendations per MR0175.
NACE Material /NC can not combine with ASME welding documents submission /WP.
(Note 11) /T01 and /T02 can be selected only one code either.
(Note 12) Refer to Subsection 13.3.2 “Option Reduced Bore Type (/R1, /R2)”
Table 13.3
Paint Color and Codes
Codes Munsell Renotation Code
Color
P1
N1.5
Black
P2
7.5BG4/1.5
Shade green
P7
—————
Metallic silver
Table 13.4
Test Pressure Value
Flange Rating
Pressure
JIS 10 K
2.1 MPa
JIS 20 K
5.0 MPa
JIS 40 K
10.0 MPa
ANSI Class 150
2.9 MPa
ANSI Class 300
7.5 MPa
ANSI Class 600
14.9 MPa
ANSI Class 900
22.4 MPa
DIN PN 10
1.5 MPa
DIN PN 16
2.4 MPa
DIN PN 25
3.8 MPa
DIN PN 40
5.9 MPa
–29
+100
+200
+300
+450
+85
+60
–29
)OXLG7HPSHUDWXUHÛ&
$PELHQW7HPSHUDWXUHÛ&
Operating range
F1304.ai
Figure 13.4 Fluid Temperature Range of High
Process Temperature Version
–196
–100
–29
0
0
–50
–20
)OXLG7HPSHUDWXUHÛ&
$PELHQW7HPSHUDWXUHÛ&
Operating range
+100
F1305.ai
–29
Figure 13.5 Fluid Temperature Range of Cryogenic
Version
