f. The following screen will be displayed (test details will differ depending on the test type
defined in the test plan):
NOTE
The above screen will be displayed only if a test plan is loaded first.
Press the
[1]
key (CONTINUE).
g. The following screen will be displayed:
Set the transformer to the tap position indicated on the LCD screen. Press the
[START]
key to run the test using the test plan.
h. The unit will start performing the test and the screen will be updated with the test
results as shown:
NOTE
For each phase (A, B, and C) a “P” or “F” will be displayed to indicate Pass or
Fail, respectively.
Press any key to continue.
If using an ATRT-03 S2 or ATRT-03A S2, continue to step i.
If using an ATRT-03B S2, continue to step k.
TEST RESULTS
RATIO
m
A %DIFF
A +10.057 0.8 0.46 P
B +10.046 0.7 0.34 P
C +10.057 0.8 0.46 P
XFMR TYPE: YND1
TAP NUMBER 1
H VTG: 1734
X VTG: 100
"START" TO RUN TEST
TP #1 YND1
TAPS: 2
TEST PLAN LOADED
1. CONTINUE
2. UNLOAD TEST PLAN
