ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL REV 2
53
d. The following screen will be displayed:
Press the [7] key (AUTO DETECT).
e. The following screen will be displayed:
1. YES
Press the [1] key (YES) if you would like to enter the transformer name plate
voltage values. The following screen will be displayed.
Type the H winding name plate voltage value using the numeric keypad. The
screen will be updated as shown below:
NAME PLATE VOLTAGE:
H : X
1,734 :
NAME PLATE VOLTAGE:
H : X
0 :
NAME PLATE VOLTAGE?
1.
YES
2. NO
1. YN d1
2. YN d3
3. YN d5
4. YN d7
5. YN d9
6. YN d111
7. AUTO DETECT
