ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL
REV 2
29
3.4
Performing Tests
3.4.1. Entering Test Record Header Information
You can enter the test record header information before performing tests. The record header
includes identifying information such as the company, station, circuit, manufacturer, etc. Once
the header information has been set, it will apply to all subsequent test records. To enter the
header information:
a. Start from the “START-UP” menu:
Press the
[2]
key (SETUP).
b. The following screen will be displayed:
ATRT-03 S2 and ATRT-03A S2
ATRT-03B S2
Press the
[1]
key (RECORD ID).
c. The following screen will be displayed:
Type the company name using the alpha-numeric keypad.
When pressing a key, the corresponding number on the key will be displayed first.
Pressing the key again will display the first letter on the key. Pressing the key again will
display the second letter on the key. For example, to type the letter “A”, you must press
the
[2]
key twice. To erase the character at the cursor position, press the
[CLEAR]
key.
Press the
[PAPER ∧ Contrast]
key to move to the next character. Press the
[PAPER
COMPANY:
_
↑
/
↓
TO POSITION
"ENTER" TO ACCEPT
1.
RECORD ID
2.
TEST VOLTAGE
3.
DISPLAY RECORD
4.
SAVE/RESTORE RECORD
5.
SET TIME
1.
RECORD ID
2.
TEST VOLTAGE
3.
PRINT RECORD
4.
SAVE/RESTORE RECORD
5.
SET TIME
1.
RUN TEST
2.
SETUP
3.
TEST PLANS
4.
DIAGNOSTIC
TIME: 11:23:01
DATE: 07/20/10
