Vanguard ATRT-03_03B S2 - Manual (Page 107)

REV 2 ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL
102
Type the test plan number using the alpha-numeric keypad and then press the
[ENTER] key. The test plan details will be printed on the unit’s printer and you
will be returned to the “START-UP” menu. A sample test plan printout is shown
in Figure 23.
d. The following screen will be displayed:
Type the test plan number using the alpha-numeric keypad and then press the
[ENTER] key. The test plan will be printed on the unit’s printer and you will be
returned to the “START-UP” menu. A sample test plan printout is shown in Figure 24.
Figure 23. Sample Printout of a Test Plan from a USB Flash Drive
PRINT TEST PLAN
NUMBER:
PRINT THUMB DRIVE TP
PLAN_
