REV 2 ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL
114
4.2 Performing a Verification Test
Use the steps below to perform a verification test on the ATRT-03 S2’s electronics:
a. Start from the “START-UP” menu:
Press the [4] key (DIAGNOSTIC).
b. The following screen will be displayed:
Press the [2] key (VERIFICATION TEST).
c. The following screen will be displayed:
Connect the H and X cables per the on-screen instructions and then press the
[ENTER]
key.
d. The ATRT-03 S2 will start performing a DELTA-DELTA test. The following screen will be
displayed momentarily:
The screen will then be updated with the test results for each phase:
DELTA-DELTA TEST
VERIFICATION test
CONNECT: H0-X0, H1-X1
H2-X2, H3-X3
"ENTER" TO CONTINUE..
1. CABLE TEST
2. VERIFICATION TEST
1. RUN TEST
2. SETUP
3. TEST PLANS
4. DIAGNOSTIC
TIME: 15:45:15
DATE: 07/20/10
