REV 2 ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL
112
4.0 DIAGNOSTICS, VERIFICATION, AND TROUBLESHOOTING
4.1 Performing an H and X Cable Diagnostic Test
Use the steps below to perform a diagnostic test on the H and X cables:
a. Start from the “START-UP” menu:
Press the [4] key (DIAGNOSTIC).
b. The following screen will be displayed:
Press the [1] key (CABLE TEST).
c. The following screen will be displayed:
Connect the H and X cables per the on-screen instructions and then press the [ENTER]
key.
d. The following screen will be displayed while the cables are being tested:
cable test
cable test
CONNECT: H0-X0, H1-X1
H2-X2, H3-X3
"ENTER" TO CONTINUE..
1. CABLE TEST
2. VERIFICATION TEST
1. RUN TEST
2. SETUP
3. TEST PLANS
4. DIAGNOSTIC
TIME: 15:45:15
DATE: 07/20/10
