ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL REV 2
49
Table 9. Descriptions of Dyn1 Test Results Elements (Column Format)
Item
Number
Description
1 Test record date and time.
2 Test record header information (see section 3.4.1).
3 Test voltage.
4 Type of transformer under test.
5 Transformer configuration diagrams (H and X).
6 H tap voltage.
7 X tap voltage.
8 Calculated ratio.
9 Measured ratio, excitation current, phase angle, and percentage error for Phase A.
10 Measured ratio, excitation current, phase angle, and percentage error for Phase B.
11 Measured ratio, excitation current, phase angle, and percentage error for Phase C.
12 Winding polarity.
