ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL REV 2
97
3.6.3. Printing a Test Plan Directory (ATRT-03 S2 and ATRT-03A S2 Only)
Follow the steps below to print a directory of the test plans stored in the unit’s Flash EEPROM
or on a connected USB Flash drive (ATRT-03 S2 and ATRT-03A S2 only):
a. Start from the “START-UP” menu:
Press the [3] key (TEST PLANS).
b. The following screen will be displayed:
Press the
[3]
key (PLAN DIRECTORY).
If a USB Flash drive is NOT connected to the unit, a directory of the test plans stored in
the unit’s Flash EEPROM will be printed, and then you will be returned to the “START-
UP” menu.
If a USB Flash drive is connected to the unit, continue to step c.
1. LOAD TEST PLAN
2. UNLOAD TEST PLAN
3. PLAN DIRECTORY
4. PRINT TEST PLAN
5. ERASE TEST PLAN
6. SAVE TEST PLAN
7. COPY TO THUMB DRIVE
1. RUN TEST
2. SETUP
3. TEST PLANS
4. DIAGNOSTIC
TIME: 15:45:15
DATE: 07/20/10
