ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL REV 2
41
Table 8. Descriptions of Single Phase Test Results Elements (Detailed Format)
Item
Number
Description
1 Test record date and time.
2 Test record header information (see section 3.4.1).
3 Test voltage.
4 Type of transformer under test.
5 H tap voltage.
6 X tap voltage.
7 Calculated ratio.
8 Measured ratio.
9 Percentage error between the calculated ratio and the measured ratio.
10 Measured transformer turns ratio.
11 Measured voltage ratio.
12 Winding phase angle.
13 Excitation current.
