REV 2 ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL

1. YES

Press the

[1]

key (YES) if you would like to enter the transformer name plate

voltage values. The following screen will be displayed.

Type the H winding name plate voltage value using the numeric keypad. The
screen will be updated as shown below:

Press the

[ENTER]

key. The screen will be updated as shown below:

Type the X winding name plate voltage value using the numeric keypad. The
screen will be updated as shown below:

Press the

[ENTER]

key. Continue to step d.

2. NO

Press the

[2]

key (NO) if you do not want to enter the transformer name plate

voltage values. Continue to step d.

NAME PLATE VOLTAGE:

H : X

2,400 : 240

NAME PLATE VOLTAGE:

H : X

2,400 : 0

NAME PLATE VOLTAGE:

H : X

2,400 :

NAME PLATE VOLTAGE:

H : X

0 :
