REV 2 ATRT-03 S2, ATRT-03A S2, AND ATRT-03B S2 USER’S MANUAL
54
Press the [ENTER] key. The screen will be updated as shown below:
Type the X winding name plate voltage value using the numeric keypad. The
screen will be updated as shown below:
Press the [ENTER] key. Continue to step f.
2. NO
Press the [2] key (NO) if you do not want to enter the transformer name plate
voltage values. Continue to step f.
f. The following screen will be displayed:
Press the
[START]
key to initiate the test.
g. The following screen will be displayed while the unit determines the transformer
configuration:
YN d AUTO DETECT
TESTING YN d1
"START" TO TEST
THREE PHASE OR
"STOP" TO ABORT
NAME PLATE VOLTAGE:
H : X
1,734 : 100
NAME PLATE VOLTAGE:
H : X
1,734 : 0
