66
5. Parameter Settings
Point No. 1
Point No. 2
Point No. 3 Point No. 3
Point No. 2 Point No. 4 Point No. 4
Point No. 1
Point No. 1
Point No. 2
Point No. 3 Point No. 3
Point No. 2 Point No. 4 Point No. 4
Point No. 1
If the actuator is moved in the order to positions 1 Ж 2 Ж 3 Ж 4, the actuator will operate differently depending on
whether or not shortcut is selected.
When shortcut is not selected
Current-limiting value during movement
(2.8 to 4 times depending on the characteristics of the actuator)
When shortcut is selected
z Current-Limiting Value at Stopping due to Missed Push-Motion (No. 91 PSFC)
The current-limiting value at stopping when the actuator misses the push-motion is defined.
Parameter
No. 91
Description
0
Current-limiting value during movement
(2.8 to 4 times depending on the characteristics of the actuator)
1 Current-limiting value during push & hold operation
