56

8. Installation Environment and Storage Environment

Dust-proof/splash-proof items

y Will not become immersed in liquid.

y Free from fine shavings generated by grinding, etc.

y Free from cutting oil.

y Free form mist of cutting fluid, grinding fluid or other liquids containing sulfur.

About IP65

IP: International Protection rating. IP is a symbol of protection characteristics.
6: Degree of protection against intrusion of solid matter

x Powder dust will not enter.

5: Degree of protection against intrusion of water

x No harmful damage will be sustained when hit by water jet directly from any direction. Spray fresh

water from all directions for 1 minute per 1 m

2

of surface area of the cover, for a total duration of at

least 3 minutes. The distance from the nozzle to the machine shall be adjusted to a range of 2.5 to 3 m,
injection pressure to 30 kPa, and flow rate to 12.5 L/min.

x Do not use the robot in an environment exceeding the protection degrees against water/powder dust

specified for the robot. Doing so may cause water or powder dust to enter, resulting in shorter robot life,
lower operation precision or malfunction.

x Supply air of the specified pressure from the air supply port for air purge provided on the side face of the

base. If air is not supplied, dust-proof/splash-proof performance will drop.

x Supplied air shall be clean, dry air free from compressor oil, etc., while the filtration level of the air filter

shall be 10

Pm or less and atmospheric dew point shall be -20qC or below.

x The robot controller is not dust-proof or splash-proof.

x Please contact IAI regarding the robot’s splash-proof performance against liquids other than water.

x The bellows may change color depending on the use environment, but discoloration does not affect the

robot’s dust-proof/splash-proof performance.

Warning

Danger
