31

4. W

iring Diagram

(3) UA and UB cables (outside robot)

DWG No. 1069444*

Base end

Arm end

Double-brazed
relay plug DF11-
10DEP-2C (by
Hirose Electric)

D-sub connector
XM2D-1501 (by
Omron)

Un-isolated terminal
(Y type) F0.3-4

Un-isolated terminal

(round type) F0.3-3

Single-brazed
crimp socket DF3-
3S-2C (by Hirose
Electric)

RED

Black

White

Black

Red

Green

White

Black

AWG22

(0.3 mm

2

)

shielded

cable

Tube

symbol

Connector

Connection

ID No.

Cable

Pin
No.

Connector

Signal

Tube

symbol

Same as above

Mini Universal MATE-
N-LOK plug housing
172166-1 (by Tyco
Electronics AMP)

Single-brazed
crimp socket DF3-
2S-2C (by Hirose
Electric)

Signal Pin

No.
